Capability to manufacture High precision powertrain components for both Automotive & Off-highway segments.
The business operates out of a modern manufacturing facility at Hosur and Chennai in Tamil Nadu and Pithampur in Madhya Pradesh.
A dedicated component park at Hosur, Tamil Nadu.
Chennai Plant is an export oriented unit catering to Global off-highway customers.
A gear is a rotating machine part having cut like teeth which mesh with another toothed part to transmit torque. Transmission uses gears to provide speed and torque conversions from a rotating power source to another device.
Type: Spur & Helical
Products: Crown gear, round gear, sun gear & pinion gear
Module Range: 1-4 & upto 7
Diameter Range: 30-260 mm & upto 500
Type of Finishing: Gear Shaving, Gear grinding
Gear ID: Plain Bore/ Spline Bore
Class: DIN 8 shaving ; DIN 6 gear grinding with bias control
Material: Alloy steel (Domestic & International specifications)
Operations: CNC - Turning, Broaching, Hobbing, Shaping, Shaving, Tooth chamfering, ID & OD grinding, Gear grinding
Machines: Liebherr, Gleason, Kanzaki, Mori Seiki, Reishauer
Application: Shafts find application in Automotive and Off-highway transmissions
A gear is a rotating machine part having cut like teeth which mesh with another toothed part to transmit torque. Transmission uses gears to provide speed and torque conversions from a rotating power source to another device.
Type: Spur & Helical
Products: Crown gear, round gear, sun gear & pinion gear
Module Range: 1-4 & upto 7
Diameter Range: 30-260 mm & upto 500
Type of Finishing: Gear Shaving, Gear grinding
Gear ID: Plain Bore/ Spline Bore
Class: DIN 8 shaving ; DIN 6 gear grinding with bias control
Material: Alloy steel (Domestic & International specifications)
Operations: CNC - Turning, Broaching, Hobbing, Shaping, Shaving, Tooth chamfering, ID & OD grinding, Gear grinding
Machines: Liebherr, Gleason, Kanzaki, Mori Seiki, Reishauer
Application: Gears find application in Automotive, Off-Highway & Railway transmissions
Type: In line Cylinder Blocks & Heads up to 4 litre capacity.
Material : Cast Iron & Aluminium
Machines pallet: HMCs- 500 & 630mm
VMC: 900 & 1200mm Table
Honing Machine: Gehring
HMC Machine: Makino, Mori & DMG
Application:
Internal gear has its teeth cut in the internal surface of a cylinder and meshes with spur gears.
Ring gears are gears of with internal gear teeth used for multiplying torque in transmissions with planetary system.
Module Range: 1-7
Diameter Range: Upto 600 mm (External)
100- 500 mm (Internal)
Height:upto 150 mm (ring gears)
Material: Alloy steel (Domestic & International specifications)
Heat Treatment: Through hardening, Nitriding, Nitro carburizing
Operations: Turning, Broaching, Hobbing & Shaping
Machines:Mori Seiki, Crane bell, Gleason, Liebherr
Application: Internal gears are used in applications involving planetary gear drives and gear couplings. Similarly ring gears are used in the transmission and engines of Automotive as well as Off-highway applications.
Shift sleeve is one of the components in the synchronizer assembly. It connects/disconnects the main gears to the output shaft in a manual gearbox. The main challenge in machining shift sleeves is usually to obtain good process security to allow for high productivity and tight tolerances. ID Range: 110 mm Max. Types: Shifter sleeves Material:Alloy steel (Domestic & International specifications) Heat Treatment: Case Carburizing & Carbo Nitriding, Plug - quenching Operations: CNC Turning, Broaching, Hobbing, Taper forming, Shifter stop milling & forming/ Tooth rounding & Tooth pointing Plug quenching Machines:Liebherr, Profilator, PICCO, TAL
Application: Sleeves find application in Automotive transmissions / transaxles
One of the highly complex and precision component that we manufacture is the planetary carrier & assemblies including sun & planet gears. The Planetary Carrier Assembly consists of Planetary carrier & Gears
Diameter Range: 100-450 mm
Height: 100- 400 mm
Material:Ductile Cast iron, steel forging
Types:Single deck/ Double deck construction
Single piece , fastened design & Welded design,
With shafts integrated
Operations: Through
Hardening, Precision Turning, Internal Broaching, Surface Broaching of
pockets, Milling, precision fine boring, planetary gear seating pocket
finishing, Grinding, Nitriding, hard part finishing, balancing
Machines:Mori Seiki, Liebherr, Gleason, Makino, Special pocket finishing machines.
Application: Carrier assemblies find application in Automotive and Off-highway transmissions
Differential case and assemblies are amongst the latest product offerings from Component BU. It allows the outer drive wheel of a vehicle to rotate faster than the inner drive wheel during a turn. This is necessary when the vehicle turns, making the wheel that is traveling around the outside of the turning curve roll farther and faster than the other.
Segment: Passenger Cars
Material: Ductile Cast Iron
Heat Treatment:Normalizing, Iso -Thermal Annealing
Critical Processes:Precision Turning, Mounting Holes Drilling & Tapping, Precision VMC of Pin Hole & Bore Honing
Machines: LMW, Hwacheon, Precision VMC, Tsugami, Honing machine, Renishaw Equator (Inspection).
Application: Differential cases and assemblies find application in Automotive and Off-highway industry
Skid steer axle is one of our many solution offerings for off-highway sector. Our Skid steer axles are specialized induction hardened and precision machined. The spindle wheel is assembled to axle housing in our state of the art dedicated assembly lines, followed by in-house painting.
Major Sub-components: Axle Housing, Axle Spindle, Bearings and Oil Seals.
Material: Housing- Ductile Iron, Axle Spindle- Forged Alloy Steel
Heat Treatment & Surface Coating:Through Hardening & Induction Hardening with complex profiles and varying case depth, PU Painting of assemblies.
Critical Processes: Precision Turning, Precision Milling, Precision Grinding, Hobbing, Drilling & Tapping, Induction Hardening, Painting.
Machines: Hyundai, LMW, Mori Seiki, Liebherr, EFD, Makino, Paint Plant (CQI 12 compliant)
Application: Skid steer axle finds application in the skid steer loader for construction industry
Advanced transmissions require a smooth shifting system for driving comfort in cars and other road vehicles. AVTEC's ingeniously designed Synchropack offers great performance, comfortable gear shifts and easily integrated into manual and automated manual transmissions.
A synchronizer, or "synchro", is a conduit for smooth shifting from one gear to next, thereby matching the speeds of the gear wheels during the shifting process.
The performance originates from careful design of synchro & friction system, tolerancing, material selection to ensure un-interrupted torque transfer providing high durability and service life.
Synchronizers play crucial role on future development of hybrid and electric vehicles
Types: Single & Multi cone (Double & Triple cone)
Sub-components: Sleeve, Hub, Inner ring, Intermediate ring, Outer ring, Dog crown, Synchro ring, Inserts
Material:TSynchro ring Brass, Steel
Coating: With and without Carbon Lining
Diameter Range: 70 to 100 mm
Application: Automotive and Off-highway transmissions
Clutch Drive Assembly is one of our many offerings to Railways. A Clutch Drive Assembly is fitted on the HHP engine assembly and provides a mechanical connection between the turbocharger to the engine gear train during the start-up, light load operation and rapid acceleration
Major Sub-components: Central Support Drive, Plate Cam, Turbo Gear, Clutch Dowel assy, Upper Idler Gear.
Material: Forged Alloy Steel, PB Bushing, HT Fasteners,
Heat Treatment & Surface Coating:Case
Hardening (case depth 2.5mm), Super Cooling (to achieve less than 2
percentage), Through Hardening, Hard Chrome & Electroless Nickel
coating.
Critical Processes:
Precision Turning, Precision Gear Grinding, Precision Bore & OD
grinding, Wire-cutting, Bush Pressing & Assembly, Rollers Assy.
Machines: Hyundai, LMW, Mori Seiki, Liebherr, Sodic, Hofler, ID & OD grinder, Spl. Assy. equipment
Application: Used on Diesel Locomotive Engine Turbo Chargers and subject to very high speed and load applications.
It is a casing that surrounds the mechanical components of a gear box. It provides mechanical support for the moving components, a mechanical protection from the outside environment to the internal components.
Segment | Off-highway & Oil Rig applications (Large) | Passenger Cars, SUVs (Automotive) |
---|---|---|
Material | Cast Iron | Aluminium (HPDC & LPDC) |
Range | Weight up to 250 Kg, Turning range- 1500 mm, Pristmatic Size- Parts with swing of 1500mm on dia, Height- 1000mm | Weight |
Critical Processes | Castings with complex cores (making castings with 23 cores), Part reference Qualification, Precision Turning, Precision Machining Center operations, Keyway milling, Pressure Testing. | HPDC/ CPDC casting, Precision Machining center operations, Pressure Testing. |
Types | Main housings, Convertor housings, Retarder housings, Covers. | Main Housings, Front & Rear Housings & Covers. |
Machines | HMCs (Mori Seiki, DMG), VMCs (Mori Seiki, Makino), VTLs (Toshiba, Hyundai), Special Purpose Pressure testing equipment. | HMCs (Mori Seiki, DMG, Hyundai, Makino), VMCs (Mori Seiki, Makino). |
Application: Housings for Off Highway & Passenger Car/ SUV transmissions
